LITEISTRY™ LTR-3RA
LITEISTRY™ offers a broad palette of architectural downlighting solutions with consistent aperture appearance, quiet ceiling design, and optical performance.
Spec Sheets
LTR 3RA SPECTRASYNCKMZ.PDF
LTR 3RAOXO.PDF
IES Files
LTR 3RA H 06L2230TD9MD DMTW LTR 3RA T S 30K TILTED 30 DEGJRH.IES
LTR 3RA H 06L2230TD9NR DMTW LTR 3RA T S 30K TILTED 30 DEGCXL.IES
LTR 3RA H 06L2230TD9WD DMTW LTR 3RA T S 30K TILTED 30 DEGFVA.IES
LTR 3RA H 06L2230TD9XW DMTW LTR 3RA T S 30K TILTED 30 DEG9KK.IES
Fixture Details
Features Benefits:
3" architectural LED round adjustable accent delivering 6002000 lm; Available with SpectraSync Tunable White and Dim-to-Warm options; NX Lighting Controls, wired and wireless capability available; Four field interchangeable beam distributions from 15 degrees to 45 degrees; Translating center beam optic allows 035 degrees vertical tilt, 362 degrees horizontal rotation; Select from three lower trim styles: Full Cut Cone, Pinhole, or Slot
Colors:
NX Lighting Controls, SpectraSync Color Tuning
Mounting:
Recessed
Optics:
Narrow, Medium, Wide, Extra Wide
Wattage:
8 - 25
Color Temperature:
2700, 3000, 3500, 4000, 5000
Lumen:
600 - 2,000; L90 @ 55,000 hours
